The contact towards the end narrows for both battery terminals.
F1 vs f2 terminal. Here are some comparison images enlarged for clarity showing the sizes of the terminals. These are flat blade type terminals which stick up at an angle from the top or side of the battery. Most emergency light applications use a f1 terminal and most emergency power backup ups applications use f2 terminals. These terminal types are designed to be attached with a push on spade insert either for your application or for charging.
The only difference that is visible to the naked eye is that the f2 is wider than the f1. One of the two f2 terminals found on a battery is typically signified by a red coloring around the terminal to designate it as the positive terminal. The f1 and the f2 are the terms we use to refer to the terminals. The f1 terminal is thinner and the f2 is wider.
See below the illustration provided to determine if you have f1 terminals or f2 terminals. F1 terminal 316 0187 48mm wide. The f1 terminal is thinner and the f2 is wider. F1 and f2 battery terminals are the most commonly used terminals on any small sla sealed lead acid battery the f refers to the terminal type as in faston connector the two terminals are different sizes.
Sometimes the application needs a larger terminal. The f1 battery terminal is 0187 wide. F1 terminals are 187 inch wide and f2 terminals are 250 inch wide. A f2 battery connector is commonly found on sealed lead acid batteries sla.
We supply original equipment manufactuer quali. F2 terminals are slightly wider than f1 terminals. At first glance they look very similar. There are terminal clips available to convert an f1 terminal into an f2.
However batteries with f1 terminal connectors are commonly used for general purpose applications and they are not meant to be discharged fully over a short period of time and batteries with f2 terminal connectors can provide you with better output and feature high rate discharge designthe f stands for faston connector which is the battery terminal. Battery specialist is canadas leader in mobile power solutions battery supplier and stored energy solutions. The f2 is 116 wider than the f1 terminal type see images below.
